B1552M Brushless DC Motor
| | B1552M | Output Power: 0.1W~4W | Weight: 46g (Approx.) |
|
Sweep and Vibration Integrated Motor with Servo Controller Personal Care: Electronic Toothbrush, Cutter | |||
| Model | Voltage(V) | No Load | Rated Load | Stall | ||||||
| Operating Range | Rated | Speed (rpm) | Current (A) | Torque (mNm) | Speed (rpm) | Current (A) | Output P. (W) | Torque (mNm) | Current (A) | |
| B1552M-S01 | 3-5 | 5 | 4500 | 0.23 | 8 | 3000 | 1.0 | 2.45 | 22.2 | 2.4 |
Characteristic: CW & CCW, Frequency range 200~350Hz,Rated frequency 250Hz.
| Notice: Data in this typical specification sheet are for other certain customer. Voltage, rated torque, speed, current, power and shaft extension feature & dimension can be changed to meet customer specific requirement. |
Outline Drawing :
Usable machine screw length 1.3mm max from motor mounting surface Unit: Millimeter
Performance Curve :
